Revit Cut Roof For Dormer

After adding a dormer cut an opening for it through the roof.

Revit cut roof for dormer.

This tutorial explains the process to create a gable dormer in revit. To create a dormer roof we first need to start with the smaller roof portion of the dormer. Edit the dormer opening to reflect the roof modification as per figure 9. You can model this in any of the 3 primary roof modelling methods but in the example i have opted to use the roof by extrusion tool.

How to model a dormer roof in revit. The dormer cut has been left selected to show the modification. Revit roof slope can seem complicated at first glance but by learning a few critical features you can create any roof shape you desire nbsp whether you want a double gable roof with 6 pyramid shaped dormers or a simple gambrel roof the basics remain the same. You can make a roof cut into an existing roof using component model in place.

Enjoy the videos and music you love upload original content and share it all with friends family and the world on youtube. After adding a dormer cut an opening for it through the roof. Select the dormer cut and then select the edit dormer opening from the ribbon as shown in figure 8. Use the join roof tool to join the dormer roof to the primary roof.

Say adding a dormer which will involve cutting out a hole in the roof using the dormer tool which leaves a hole in the existing phase view of the roof as well as the new construction view. Create the walls and roof elements that make up the dormer. First a work plane needs to be decided upon. Use the join roof tool to join the dormer roof to the primary roof.

Change the visual style back to shaded to show the finished item as in. Create the walls and roof elements that make up the dormer. The next step is to cut a dormer opening in the main roof. From the home tab select dormer opening.

Select the top wall of the dormer and move it down so it is below the valleys.
